Wire Reinforced Aluminum Flexible Duct Machine AFD-600 Series

The Wire reinforced aluminum flexible duct machine AFD-600 series is specially producing foraluminum flexible ducts with aluminum foil or metalized PET film with steel wire reinforced for ventilation purpose like the air condition.

Summary

Features

1) Upgrade high speed model.

2) The auto cutting new design, More easy to control and adjust diameters.

3) Fast setting up diameters.

4) Functions all control in PLC (Touch screen)

5) Auto stop when material finished.

1	Model	PAD-500
2	Diameter range	80mm~600mm
3	Length of aluminum tube	1-10m
4	Raw material	Metalized PET film/aluminum PET/ pvc/Clear PET
6	Material width	45/50/55/65mm
7	Suitable material thickness	0.012-0.1
8	Temperature	40~120 centigrade
9	Electric heating power	2.4kW
10	Feeding speed:	1-60 m/min, adjustable
11	Dimension	2200 x 820 x 1550mm
12	Weight	500KG
13	Motor power	1.5 KW
14	Wire diameter	0.8-1.4
15	Air pressure	0.4-0.6Mpa

Application

Wire reinforced aluminum flexible duct machine is mainly used for range hoods, integrated environmental protection stoves, dryers, bathroom heaters and other ventilation and air systems, used for various mechanical ventilation. It has exhaust hoses that are resistant to temperature, acid and alkali, chemistry, exhaust gas, etc. Extremely flammable. Very high flexibility and flexibility,

After-Sale Service

We offer one-year warranty period since the date B/L for Wire reinforced aluminum flexible duct machine. During warranty period, we will offer free pars of the flex Stainless steel duct machine if quality problem, and the shipping cost by customer.

You are welcome to visit us for Wire reinforced aluminum flexible duct machine inspection and training before shipment. Also we can have online support for Wire reinforced aluminum flexible duct machine installation and troubleshooting by email or video call.
