This Hole perforated type filter core machine is for producing round air duct for various uses, such as for HVAC round ducts, oval ducts, chimney flue, filter core, posttension pipe, drain pipe, etc.
Advantages
1 Special designed steel mould, light & long life
2 Round roller shear, without noise and burrs
3 Large diameter range
4 PLC control, convenient operation
5 Auto unloading rack, low labor cost
Main Technical Data
1 Diameter of round tubes: 100mm ~ 600mm.
2 Max. tube length: 3000mm.
3 Thickness of strip: 0.5 ~ 1.0mm
4 Width of strip: 137mm (can be customized)
5 Strip speed: 1~35m/min, adjustable
6 Suitable strip material: galvanized steel, mild steel, etc.
7 Weight: 2500kg
8 Power of main motor: 11kw
9 Power of hydraulic motor: 4kw
10 Power of cooling water pump motor: 125W
11 Power of material feeding motor: 125W
Main Configuration
1 Uncoiler: mechanical expanding type, capacity 1200kg, inner diameter range 480-610mm, outer diameter 1000mm.
2 Control system: with inverter, PLC control
3 Driving system: Spiral subulate gear type decelerator (low noise, large moment)
4 Material of forming rollers: GCr15 bearing steel, quenched, HRC58-62
Accessories accompanied with the machine
1 Unloading rack: one sets, 2000mm long, pneumatic drive
2 Four press-adjusting rollers (changed to suit different thickness)
3 One set of special tools.
