Summary
SQUARE-LOCK FLEXIBLE HOSE MACHINE mainly produces metal hoses, which can be used in wire and cable, solid-liquid processing, automotive, sanitary, electrical and communications industries, etc.
BOBO Machine Features
● Continuously producing swage steel flexible hose by using stainless steel or copper, iron, aluminum, etc.
● Advanced imported transducer speed adjusting system and perfect processing technics make the machine low electric consumption, no noise, easy operation and stable work.
● Finished products have good tensile strength and yield strength.
● One worker can operate several machines at same time.
● Finished hose may be used for sanitary, electric bushing (sleeve), etc.
Main Technical Data
No. | Parameter | Data |
1 | Diameter range | ￠12.2mm-￠102.5mm |
2 | Width of material | 8.6mm-21mm |
3 | Thickness of material | 0.2mm-0.5mm |
4 | Production speed | 2.0-2.5m/min |
5 | Motor power | 1.1kW-2.2kW |
6 | Electric system | 380V, 50Hz, 3Phase |
7 | Dimension | 950mm x 850mm x 1400mm |
8 | Weight | 600kg-1200kg |
Application
SQUARE-LOCK FLEXIBLE HOSE MACHINE is made of stainless steel belt and is wound with a single hook structure. According to different application requirements, it has developed three grades of light, intermediate and heavy grades. The size system caters to the specifications commonly used in the Asian market. . The product has excellent flexibility and is suitable for most ambient temperature conditions. It is a low fire risk product. Its electrical characteristics and various mechanical properties have passed the test requirements of the IEC 61386 standard. Can be applied to electrical protection of buildings, railway systems, ships, elevators, etc.
After-Sale Service
We offer one-year warranty period since the date B/L for flexible hose machine. During warranty period, we will offer free pars of the metal flexible hose machine if quality problem, and the shipping cost by customer.
You are welcome to visit us for square lock flexible hose machine inspection and training before shipment. Also we can have online support for square lock flexible hose machine installation and troubleshooting by email or video call.
