Aluminum flexible air duct manufacturers machine

The Aluminum flexible air duct manufacturers machine is mainly used to produce the flexible air duct from aluminum strip by spiral lock forming process. The suitable material cab be aluminum foil or stainless steel strip, both single and double layer will be ok.

Feature of Aluminum flexible air duct manufacturers machine

* Automatic forming, cutting and compressing process controlled by PLC.
* Suitable material for both aluminum foil and stainless steel strip.
* Double layer aluminum foil will be available by our speical design

Main Technical data of Aluminum flexible air duct manufacturers machine

1	Duct Diameter	60-300mm (80-450mm)
2	Duct length	Endless
3	Aluminum strip size	0.05-0.15mm thick 40-55mm wide
4	Forming speed	1-5m/min
5	Main motor power	1.5KW
6	Dimension	1200 x 550 x 1200 mm
7	Weight	850 KG
